1" 2" 3 Inch Diameter HDPE Water Supply Pipe Rolls HDPE Poly Pipe Water Supply Pe Coil Pipe Plastic
Other recommendations for your business
Contact us
Quik Detail
Type | HDPE Water Pressure Pipe |
---|---|
Feature | Flexible, High Pressure, Light Weight, Non-Toxic, Anti-UV, Durable, Eco Friendly, Heat Resistant, Anti-Corrosion, No smell, high toughness, Cost-effective, chemical resistant, ease of connection & installation |
Shape | ROUND |
Application | Water Supply, Drainage and Sewerage Under Pressure, Water Supply, Drainage and Sewerage Under Pressure |
Place of Origin | Tianjin, China |
Brand Name | HUAXIANG |
Model Number | HDPE Pipe Under Pressure |
Material | HDPE |
Specification | DN20mm-DN1200mm |
Length | Customizable |
Standard | ISO4427, EN, DIN, AS, ASTM |
Processing Service | Moulding, Cutting, Specification customization, Length customization, Color customization, Logo customization |
Color | Black, White |
Normal pressure | 0.4Mpa to 2.0Mpa |
Connection | Butt welding, Socket fusion, Electrofusion, Flanged connection |
Life span | 50 Years Under Normal Conditions |
Certificate | ISO4427,ISO9001,CE |
Working temperature | --40℃ to 60℃ |
Production capacity | 110000 tons/year |
Sample | Availiable |
Product Detail
提示信息
Welcome To Huaxiang Pipe Technology Co., Ltd.
Nominal Diameter (mm) | Nominal Diameter (inch) | Wall Thickness (mm) | ||||
SDR26 | SDR21 | SDR17 | SDR13.6 | SDR11 | ||
PN6 | PN8 | PN10 | PN12.5 | PN16 | ||
20 |
3/4" | -- | -- | -- | -- | 2.3 |
25 | 1" | -- | -- | -- | 2.3 | 2.3 |
32 | 1 1/4" | -- | -- | 2.3 | 2.4 | 3 |
40 | 1 1/2" | -- | 2.3 | 2.4 | 3 | 3.7 |
50 | 2" |
2.3 |
2.4 | 3 | 3.7 | 4.6 |
63 | 2 1/2" | 2.5 | 3 | 3.8 | 4.7 | 5.8 |
75 | 3" | 2.9 | 3.6 | 4.5 | 5.6 | 6.8 |
90 | 3 1/2" | 3.5 | 4.3 | 5.4 | 6.7 | 8.2 |
110 | 4 1/4" | 4.2 | 5.3 | 6.6 | 8.1 | 10 |
125 | 5" | 4.8 | 6 | 7.4 | 9.2 | 11.4 |
140 | 5 1/2" | 5.4 | 6.7 | 8.3 | 10.3 | 12.7 |
160 | 6 1/4" | 6.2 | 7.7 | 9.5 | 11.8 | 14.6 |
180 | 7" | 6.9 | 8.6 | 10.7 | 13.3 | 16.4 |
200 | 8" | 7.7 | 9.6 | 11.9 | 14.7 | 18.2 |
225 | 9" | 8.6 | 10.8 | 13.4 | 16.6 | 20.5 |
250 | 10" | 9.6 | 11.9 | 14.8 | 18.4 | 22.7 |
280 | 11" | 10.7 | 13.4 | 16.6 | 20.6 | 25.4 |
315 | 12 1/2" | 12.1 | 15 | 18.7 | 23.2 | 28.6 |
355 | 14" | 13.6 | 16.9 | 21.1 | 26.1 | 32.2 |
400 | 15 3/4" | 15.3 | 19.1 | 23.7 | 29.4 | 36.3 |
450 | 17 3/4" | 17.2 | 21.5 | 26.7 | 33.1 | 40.9 |
500 | 19 3/4" | 19.1 | 23.9 | 29.6 | 36.8 | 45.4 |
560 | 22" | 21.4 | 26.7 | 33.2 | 41.2 | 50.8 |
630 | 24 3/4" | 24.1 | 30 | 37.4 | 46.3 | 57.2 |
710 | 28" | 27.2 | 33.9 | 42.1 | 52.2 | 64.5 |
800 | 31 1/2" | 30.6 | 38.1 | 47.4 | 58.8 | 72.6 |
900 | 35 1/2" | 34.4 | 42.9 | 43.3 | 66.2 | 81.7 |
1000 | 39 1/2" | 38.2 | 47.7 | 59.3 | 72.5 | 90.2 |
1200 | 47 1/4" | 45.9 | 57.2 | 67.9 | 88.2 | -- |
