220v 380v 415v AVR 100kva 80kva 60kva 50kva 3 Phase Automatic Voltage Regulator 100 Kva Industrial Stabilizer
US $75.00-79.00 / piece
1 piece(s)Minimum order
Place of Origin:
Anhui, China
Brand Name:
Green Energy
Model Number:
TNS
Use:
SVC
Phase:
Three Phase
Current Type:
AC
Privacy Policy:
Samples are free within a certain price range
Other recommendations for your business
$47.00-108.00
1 piece (MOQ)
$102.00-275.00
1 piece (MOQ)
$18.00-25.00
1 piece (MOQ)
$98.00-155.00
1 set (MOQ)
$142.20-153.00
1 piece (MOQ) Contact us
Quik Detail
| Place of Origin | Anhui, China |
|---|---|
| Brand Name | Green Energy |
| Model Number | TNS |
| Use | SVC |
| Phase | Three Phase |
| Current Type | AC |
| Certification | ISO CE |
| Standard | IEC60076 |
| Rated capacity | 10KVA-2000KVA |
| Winding material | Copper\Aluminum |
| Warranty | 2 Years |
| Operating temperature | 40 To+180 |
| Protection | Overload |
| Display | LED |
| Input Voltage | 304V-456V or customized |
| Output voltage | 380V or customized |
Product Detail
Products Description
TNS Voltage Stabilizer
Overload protection
When the connected equipment has abnormalities such as overload or short circuit, the voltage stabilizer protection device will work and cut off the input power
Mechanical failure protection
When the mechanical voltage regulator fails/causes unregulated voltage, the voltage stabilizer will start the protection device to cut off the output power supply
Open phase/phase sequence protection
When the input power grid is open phase or the input phase sequence wiring is wrong, the voltage stabilizer will not start/output no power
TNS Series single and three phase high precision automatic AC voltage regulator is composed of contact type auto voltage regulator, servo motor and automatic control circuit. When the grid voltage is unstable for the load changes, the automatic sampling control circuit sends a signal to drive the servo motor, adjust the position of the auto-coupler carbon brush, adjust the output voltage to the rated value and reach a steady state.
TNS series high-precision AC voltage regulator has the function of direct power supply. It has many advantages such variety, fully specifications and beautiful appearance. It has the advantages of no waveform distortion, high efficiency, reliable performance, long-term operation, etc. It has short delay, overvoltage and other protection functions. It can add long delay and undervoltage protection according to the needs of users. The product can be widely used in any place of electricity, it is an ideal regulated power supply to ensure the normal operation of your electrical equipment.
TNS series high-precision automatic three phase AC regulated power supply is composed of single phase TND series high precision automatic regulated power supply. Three phase and phase to phase adjustment ensures stable and safe voltage of each phase. The grid input is three phase four wire system. Star(Y-shaped) connection, the output can be used three-phase four wire system or three phase three wire system.
TNS series high-precision AC voltage regulator has the function of direct power supply. It has many advantages such variety, fully specifications and beautiful appearance. It has the advantages of no waveform distortion, high efficiency, reliable performance, long-term operation, etc. It has short delay, overvoltage and other protection functions. It can add long delay and undervoltage protection according to the needs of users. The product can be widely used in any place of electricity, it is an ideal regulated power supply to ensure the normal operation of your electrical equipment.
TNS series high-precision automatic three phase AC regulated power supply is composed of single phase TND series high precision automatic regulated power supply. Three phase and phase to phase adjustment ensures stable and safe voltage of each phase. The grid input is three phase four wire system. Star(Y-shaped) connection, the output can be used three-phase four wire system or three phase three wire system.
Input voltage | Regular models 260-450V/500V, Customized ultra low voltage models |
Output voltage | 380V |
Voltage regulation accuracy | 3% |
Frequency | 50Hz/60Hz |
Overvoltage protection value | Output voltage 430V±4V |
Undervoltage protection value | Output voltage 320V±4V, regularly not set undervoltage protection |
Load power factor | 0.8 |
Adjust time | When the voltage change by10%<1S |
Waveform distortion | No additional waveform distortion |
Dielectric strength | 1500V/1min |
Insulation resistance | Three phase >2MΩ |
Insulation class | Class E |
Working environment | Temperature :-10℃ to +40℃, Humidity: <95% |
Effectiveness | >95% |
Temperature rise | <60℃ |
Production Details
Model | Voltage regulation range | Product size | Package dimension | Net weight KGS | Gross weight KGS |
TNS-1500VA | 260V-450V | 485*320*170mm | 530*355*225mm | 13 | 15.5 |
TNS-3000VA | 260V-450V | 485*320*170mm | 530*355*225mm | 17.5 | 20 |
TNS-4500VA | 260V-450V | 485*320*170mm | 530*355*225mm | 18 | 20.6 |
TNS-6KVA | 260V-450V | 275*307*673mm | 330*360*760mm | 26.1 | 30.8 |
TNS-10KVA | 260V-450V | 310*330*760mm | 375*385*850mm | 37 | 43 |
TNS-15KVA | 260V-450V | 340*360*855mm | 400*420*950mm | 46 | 53 |
TNS-20KVA | 260V-450V | 460*422*880mm | 470*505*970mm | 92.8 | 102 |
TNS-30KVA | 260V-450V | 460*422*880mm | 470*505*970mm | 102 | 111 |
TNS-40KVA | 260V-450V | 460*422*880mm | 470*505*970mm | 114.5 | 123.5 |
TNS-50KVA | 260V-500V | 550*455*1160mm | 610*510*1310mm | 141 | 150 |
TNS-60KVA | 260V-500V | 550*455*1160mm | 610*510*1310mm | 161 | 172 |
TNS-80KVA | 260V-500V | 620*520*1330mm | 680*580*1470mm | 185 | 195 |
TNS-100KVA | 260V-500V | 620*520*1330mm | 680*580*1470mm | 205 | 215 |
Related Product
Company Profile
GREEN ENERGY ELECTRIC Group is located in Hefei City, Anhui Province, near Shanghai, with more than 10 years of professional manufacturing experience, specializing in the production of voltage stabilizer/voltage regulators, isolation transformers, voltage transformer, voltage converter, reactor, inverter and other electrical equipment class products.
Since its establishment, the company has insisted on taking science and technology as the guide and backed by strong technology for many years, actively introducing foreign advanced technology, continuously improving and perfecting products, professional management, and the products sell well all over the country. Some products are exported to the Philippines, Indonesia, Thailand , Italy, the United Kingdom, the United States, Canada, Africa and South American countries, and are well received by customers.
We can do OEM (Original Equipment Manufacturer) and ODM (Original Design Manufacturer) for all customers. Under normal circumstances, orders with small quantities can be produced and delivered within 10 days. Orders with large quantities will take about 25 days to deliver.
Welcome to come to consult and purchase！
Package & Delivery
Packaging: Wooden case or according to client's requirements
The requirements for the making and reinforcement of packing boxes were strictly in accordance with the international standards.
Shipping: Land transportation/Ocean transportation/Express
Our products have been shipped all around the world, with an extensive logistic network, we provide the best transportation option for our clients.
Over 20 years of business experience makes us pack well and deliver fast, satisfying our customers all over the world!
Shipping: Land transportation/Ocean transportation/Express
Our products have been shipped all around the world, with an extensive logistic network, we provide the best transportation option for our clients.
Over 20 years of business experience makes us pack well and deliver fast, satisfying our customers all over the world!
FAQ
Q1. What is the Guarantee?
A1: Two years (for free) from the date of B/L. Besides, any of the spare parts can be supplied all the time, that is, during the guarantee period and after the guarantee period.
Important:
(1). The efficiency of our Voltage Regulators / Stabilizers are 90% to 95% (some series of them reaches 95%), please don’t let them work overload!
(2). Please make sure that all the electric wires are connected correctly according to the electric diagram
Q2. What's the payment terms?
A2: We accept LC, T/T, PayPal, Western Union, Money Gram(Small-amount payment).
Q3. How's the delivery time ?
A3: Usually it will take about one weeks for production. Depending on the product, the quantity is different, and the specific production time is different, please consult the staff for details.
Q4. Can put our logo on product?
A4: Yes, it is! Our products can be Customized. We can design and produce according to our customers’ specific requirements.
Q5. What is the MOQ?
A5: For the small capacity products (Automatic Voltage Regulators/Stabilizers) of the default configuration, it is 10 sets. For the big capacity products, it is 1 set.
Q6. What is the standard of package?
A6: For the small capacity, it use carton, but for big capacity, we should use strong plywood box for protection.
Q7. Could you offer Form A, Form B or C/O ?
A7: It totally not a problem. We can prepare relative documents to foreign affairs office or other office to apply for this certificate.
Q8. What kind of certificate you have ?
A8: Our company already achieve ISO9001, and for products, we have SGS, TUV, CE, etc.
Q9. Where is your market?
A9: Our products are popular in North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East,Eastern Asia, Western Europe and so on.Some of them are our regular customers and some of them are developing. We hope you can join us and make mutual benefit from our cooperation.
