ASTM A537 Class 1 2 3 Pressure Vessel Steel Plate ASME SA537 Cl1 Cl2 Cl3 Carbon Steel Sheet Price
US $0.60-0.80 / kilogram
1000 kilogram(s)Minimum order
Place of Origin:
Tianjin, China
Brand Name:
YCT
Application:
Boiler Plate
Type:
Steel Sheet, Hot Rolled Steel Sheet
Thickness:
3-500mm
Standard:
AiSi
Privacy Policy:
Samples are free within a certain price range
Other recommendations for your business
$465.00-580.00
25 tons (MOQ)
$520.00-565.00
5 tons (MOQ)
$560.00-582.00
5 tons (MOQ)
$511.00-600.00
8 tons (MOQ)
$515.00-585.00
5 tons (MOQ) Contact us
Quik Detail
| Place of Origin | Tianjin, China |
|---|---|
| Brand Name | YCT |
| Application | Boiler Plate |
| Type | Steel Sheet, Hot Rolled Steel Sheet |
| Thickness | 3-500mm |
| Standard | AiSi |
| Width | 1000mm-2500mm |
| Length | As required |
| Certificate | ce, ISO9001 |
| Grade | A537 class 1 2 3 |
| Tolerance | ±1% |
| Processing Service | Bending, Welding, Decoiling, Cutting, Punching |
| Skin Pass | Yes |
| Alloy Or Not | Non-Alloy |
| Delivery Time | within 7 days |
| Shape | Flat Plate |
| Material | A537 class 1 2 3 |
| Usage | Boiler and pressure vessel plate |
| Packing | Standard Seaworthy Packing |
| Payment term | 30%TT Advance + 70% Balance |
| Special Use | High-strength Steel Plate |
| Model Number | carbon steel plate |
Product Detail
Product Description
Boiler and Pressure Vessel Steel Coil / Sheet / Plate
ASTM A537 Steel Plates: A537 class 1 / A537 CL1, A537 class 2 / A537 CL2, A537 class 3 / A537 CL3
ASTM A537 steel plates are heat-treated carbon- manganese-silicon steel plates intended for fusion welded pressure vessels and structures. A537 pressure vessel steel plates are available in three classes: A537 class 1, A537 class 2, A537 class 3.
The maximum thickness of A537 class 1 steel plate is 4 in. [100 mm], the max. A537 class 2 and A537 class 3 pressure vessel steel plate thickness is 6 in. [150 mm].
A537 class 1 steel plate shall be normalized. A537 class 2 steel plate and A537 class 3 steel plate shall be quenched and tempered(Q+T).
ASTM A537 Steel Plates: A537 class 1 / A537 CL1, A537 class 2 / A537 CL2, A537 class 3 / A537 CL3
ASTM A537 steel plates are heat-treated carbon- manganese-silicon steel plates intended for fusion welded pressure vessels and structures. A537 pressure vessel steel plates are available in three classes: A537 class 1, A537 class 2, A537 class 3.
The maximum thickness of A537 class 1 steel plate is 4 in. [100 mm], the max. A537 class 2 and A537 class 3 pressure vessel steel plate thickness is 6 in. [150 mm].
A537 class 1 steel plate shall be normalized. A537 class 2 steel plate and A537 class 3 steel plate shall be quenched and tempered(Q+T).
Specification
ASTM A537 Steel Plate Chemical Composition: | ||||||||||||||||
C | Si | Mn | P | S | Cu | Ni | Cr | Mo | ||||||||
0.24 | 0.13-0.55 | 0.64-1.72 | 0.025 | 0.025 | 0.38 | 0.28 | 0.29 | 0.09 | ||||||||
ASTM A537 Steel Plate Mechanical Properties: | ||||||
Grade | Thickness | Tensile Strength | Yield Strength | |||
A537 class 1 | mm | ksi [MPa] | ksi [Mpa] min. | |||
≤65mm | 70-90 [485-620] | 50 [345] | ||||
65-100mm | 65-85 [450-585] | 45 [310] | ||||
100-150mm | - | - | ||||
A537 class 2 | ≤65mm | 80-100 [550-690] | 60 [415] | |||
65-100mm | 75-95 [515-655] | 55 [380] | ||||
100-150mm | 70-90 [485-620] | 46 [315] | ||||
A537 class 3 | ≤65mm | 80-100 [550-690] | 55 [380] | |||
65-100mm | 75-95 [515-655] | 50 [345] | ||||
100-150mm | 70-90 [485-620] | 40 [275] | ||||
Packing & Delivery
Company Profile
TJYCT Steel Co., Ltd is a comprehensive company, who is founded in 2008. Specialized in stainless steel, alloy steel, galvanized steel in pipe and tube,plate and coil,profiles.
We are located in Tianjin Province, the Steel base of China, It is well-known all over the world. We are close to Tianjin Seaport, that is much convenient in carriage. Since our establishment, we have always adhered to the business policy of "Quality for Survival, Product for Development, Credibility for Cooperation and Service for Customer".
Under the guidance of this business policy, our company acts as a perennial distributor of steel pipe, steel plate, steel coil, steel rod, steel profiles of Angang Steel, HBIS, JISCO,SGHB ,and etc. Modern large-scale outdoor storage and indoor storage have been set up in our company, and 20,000 tons of available goods have been prepared.
We welcome all users,manufacturers and traders to cooperate with us.
