Dc 12V Touch Screen Membrane 6 Gang Switch Panel for Car Truck Caravan
Other recommendations for your business
Contact us
Quik Detail
| Whether the smart | NO |
|---|---|
| Place of Origin | Guangdong, China |
| Brand Name | Yujie |
| Model Number | YJ-TSP-02 |
| Max. Current | 40A |
| Max. Voltage | 12V |
| Mechanical Life | 500000 |
| IP level | IP53 |
| Color | Black |
| Input | 12V-24V |
| Output Voltage | 5V |
| Output Current | 3.1A 10A 20A |
| Operating temperature: | -10 ° C to +50 ° C |
| Storage temperature: | -20 ° C ~ +60 ° C |
| Products name | control switch panel |
| Keyword | 6 gang interrupteur du panneau |
| Waterproof | IP67 |
Product Detail
Description:
Material :carbon steel100% brand new and high quality
Material: Polyester
Color: Red
6 Gang capacitive touch screen panel, 15pin VGA transmission cable
Input: DC12V/24V
Output Voltage: 5V
Output Current: 3.1A 10A 20A
Operating temperature: -10 ° C to +50 ° C;
Storage temperature: -20 ° C ~ +60 ° C;
Working humidity: 35 ~ 85% RH;
Storage humidity: 5 ~ 95% RH
LED color: ON:Blue OFF:White
Reverse polarity protection, Overvoltage protection and Overcurrent protection.
Built in resettable fuse(PPTC)
Size:
Host: 13.5cm x 8.5cm x 3.5cm
Panel: 10cm x 8cm x 2.5cm
Hole: 4.8cm x 1.8cm
Due to the difference between different monitors, the picture may not reflect the actual color of the item. Thank you!
please allow 1-2CM differs due to manual measurement, thanks!
Package includes:
1 x touch srceen panel
1 x circuit control box
1 x 15pin VGA cable
20 x label sticker
2 x input wire
6 x output wire
6 x Stainless steel screws
