HERMANN Mini Beer Brewing Machine 500L Brewery Equipment/Brewhouse System Beer Equipment Manufacture
US $39,999.00 / set
1 set(s)Minimum order
processing:
Fermenting Equipment
place of origin:
Shandong, China
brand name:
HEM
processing types:
Alcohol
voltage:
Customized
power(w):
Customized
Privacy Policy:
Samples are free within a certain price range
Other recommendations for your business
$12,500.00-12,800.00
1 set (MOQ)
$6,480.00-7,020.00
1 set (MOQ)
$11,070.00-11,520.00
1 set (MOQ)
$5,700.00-6,000.00
1 set (MOQ)
$7,300.00-7,800.00
1 set (MOQ)
$5,570.00-5,870.00
1 set (MOQ)
$24,500.00-25,000.00
1 set (MOQ) Contact us
Quik Detail
| processing | Fermenting Equipment |
|---|---|
| place of origin | Shandong, China |
| brand name | HEM |
| processing types | Alcohol |
| voltage | Customized |
| power(w) | Customized |
| dimension(l*w*h) | Customized |
| weight | 2000 KG |
| warranty | 12 months |
| Machinery Capacity | 50l, 100L, 200L, 300L, 500L, 800L, 1000L, 1500L, 2000L, 2500L, 3000L, 3500L, 5000L, 10000L, 20000L |
| machinery test report | Provided |
| core components | Gearbox, motor, Gear, Pump, Pressure vessel, PLC, Bearing |
| key selling points | Easy to Operate |
| video outgoing-inspection | Provided |
| After-sales Service Provided | Engineers available to service machinery overseas |
| Material | Stainless Steel 304 |
| Heating way | Steam Heating Method |
| Thickness of Tanks | Inner 3mm/external 2mm |
| Heat Insulation | Rock Wool |
| Control system | PLC |
| Surface | Brushed Stainless Steel |
| Capacity | 100-5000L |
| Appearance | Brushed |
| MOQ | 1 Set |
| Showroom Location | France, India, Russia, Thailand, Argentina, South Korea |
| Condition | New |
| Warranty of core components | 1 Year |
| Marketing Type | Ordinary Product |
| Applicable Industries | hotels, Manufacturing Plant, Food & Beverage Factory, Food & Beverage Shops, brewery |
Product Detail
HERMANN Mini Beer Brewing Machine 500L Brewery Equipment/Brewhouse System beer equipment manufacture
1.Malt Milling System | Mill machine | Stainless steel/Carbon steel | |
Grist case | Stainless steel | ||
Flexible conveyor | Outer PPR or Stainless steel | ||
2.Brewhouse System | Mash tun | Inner:3mm;outer:2mm Motor agitation Steam jackets/Electric elements/Fire direct heating | |
Lauter tun | Inner:3mm;outer:2mm Rack system; False bottom filter | ||
Kettle tun | Inner:3mm;outer:2mm Steam jackets/Electric elements/Fire direct heating | ||
Whirlpool tun | Inner:3mm;outer:2mm Side tangent whirlpool inlet | ||
Hot water tank | Inner:3mm;outer:2mm Steam jackets/Electric elements/Fire direct heating | ||
Accessories | Mash pump;;Heat exchange plate;Hop back system; Brewhouse Pipes; | ||
3.Fermentation System | Fermentation tank | Pressure:3Bar; Inner:3mm;outer:2mm;with insulation; Cooling jackets; | |
Accessories | Yeast Saving Tank; | ||
4.Cooling System | Glycol water tank | Inner:3mm;outer:2mm | |
Accessories | Chiller; Glycol water pump; Pipes & Valves; | ||
5.CIP System | Acid tank | Pump; Pipes & Valves | |
Caustic tank | |||
Trolley | |||
Accessories of the CIP System | |||
6.Control System | Automatic/Semi-auto | ||
7.Filtering System | Candle type diatomite filter/Membrane filter/Bag filter | ||
Bright beer tank | Double-layer with insulation; | ||
8.Filling System | Glass bottle line | Capacity:800-1200 BPH Washing heads:8;Filling heads:8;Capping heads:3 Optional: Capacity:1500-2000 BPH Washing heads:16;Filling heads:16;Capping heads:6 | |
Canning line | Capacity:1000-1500 CPH Filling heads:12;Capping heads:1 | ||
Keg system | Keg filling machine;Keg washing machine;Keg washing and filling unity machine; | ||
For more product details, please contact us.
Shandong Hermann Biological Engineering Co.,Ltd. is an equipment manufacturer focusing on the global biological fermentation industry, with more than 19 years' experience in the field of biological engineering industry, beer (beverage) brewing equipment and filling machine industry, always specializing in the manufacture of high-end equipment. Company is major engaged in beer brewing equiment,providing high-end integrated services from product design,production,processing,installation and technical process reaining for large,mediuu,micro breweries,hotel restaurants,bar brewing enthusiasts.
·Germany Brau Beviale 2018
·Shanghai CBC Exhibition 2018
·Germany Brau Beviale 2019
·Shanghai CBC Exhibition 2019
·The 101th China Food and Drink Fair
·2019 HERMANN CUP the 12th Internati-
onal Conference of Beer and Beverage
Technology
· 30T Fermenters
· Canada 2000L Brewery Plant
· Shanghai 1000L Brewpub
· Domestic 3000L Brewpub
· Netherlands 2000L BBT
· Argentina 2000L Fermenter
· KAERA 1000L Brewing System
· 20000L Fermenters in China
1.How to achieve temperature control?
The PLC or digital dispalyer could control the temperature by connecting with the PT 100 sensor.The brewing tanks with rock wool to keep warm,the fermenters and bright beer tank with PU as cooling jacket to keep cool.
2.Which countries your products are exported to?
Our stainless steel microbrewery equipment are sold all over the world and with related certifications.
3.How to use your machine?
We have paper instructions in English, and we will teach till you do it well.
4.How long is your delivery time?
Usually it takes about 50 working days to manufacture a brewery.Depending on the size of the brewery,the amount of custom designed equipment,our general workload and the way of shipping this period can be shorter or longer.
5.Do you provide after-sales service?
Yes,we could provide after-sales service.We have many professional engineers, they can go to your place and teach your person installation and brewing.
1. Container loading(20GP/40GP/40HQ).
2. Packed with plastic film and iron frame for main tank.Fittings use iron cabinet.
3. Customer's requirements available.
