Peacefair PZEM-022 Digital Voltage Meter Smart Electricity Current Frequency Power Kwh Wattmeter Single Phase Energy Meter
US $8.00-10.00 / piece
1 piece(s)Minimum order
Application:
Industrial, IoT, Household, Telecommunication, electric power
Feature:
Safety, Light Weight
Place of Origin:
Zhejiang, China
Brand Name:
Peacefair
Model Number:
PZEM-022
Display Type:
Digital Only
Privacy Policy:
Samples are free within a certain price range
Other recommendations for your business
Contact us
Quik Detail
| Application | Industrial, IoT, Household, Telecommunication, electric power |
|---|---|
| Feature | Safety, Light Weight |
| Place of Origin | Zhejiang, China |
| Brand Name | Peacefair |
| Model Number | PZEM-022 |
| Display Type | Digital Only |
| Phase | Single Phase |
| Measuring Energy Range | 0-9999kwh |
| Accuracy Class | 1.0grade |
| Output Voltage | 80-260V |
| Operating Temperature | -10-60degree |
| Dimensions | 89.6*49.6*24.3mm |
| backlight color | blue |
| Certificate | CE FCC |
| current | 100A |
| Type | Energy Digital Kwh Meter |
| Display | LCD |
| Frequency | 45-65Hz |
| Weight | 159g |
| Power factor | 0~1PF |
| Accessory | split CT |
| Starting current (A) | 0.001A |
Product Detail
Product Description
Peacefair PZEM-022 Digital Voltage Meter Smart Electricity Current Frequency Power Kwh Wattmeter Single Phase Energy Meter
Product Type | PZEM-022 |
Current Range | 0-100A（with open CT） |
Voltage Range | AC 80-260V |
1.Measure voltage, current, active power, energy, frequency, power factor 2. Overload alarm 3. Power alarm threshold preset 4. Reset energy 5. Store data when power off. 6. Large-screen LCD 7. Backlight function. | |
Weight | 159g |
Backlight control
Short press the key to turn on or off the backlight, the backlight has memory function, it can store the on or off state when power off.
Reset energy
Step1: Long press the key for 5 seconds until the energy value flash, then release the key.
Step2: Short press the key, energy value is cleared and exit the reset flashing state.
Step3: If there is no operate within 5 seconds, it is not cleared,will exit reset state.
Set power alarm threshold
Step1: Long press the key until the LCD display “SET CLr”, then release the key to enter the setting state
Step2: Power area display power alarm value and the last digit begin to flash, short press to plus 1,
If no operate over 3 secs, it will switch digit position automatically, the setting method is as same as above.
Step3: After finish setting, long press the key over 5 secs to store automatically and exit, the range of power threshold is 0.0～22kW.
Step2: Short press the key, energy value is cleared and exit the reset flashing state.
Step3: If there is no operate within 5 seconds, it is not cleared,will exit reset state.
Set power alarm threshold
Step1: Long press the key until the LCD display “SET CLr”, then release the key to enter the setting state
Step2: Power area display power alarm value and the last digit begin to flash, short press to plus 1,
If no operate over 3 secs, it will switch digit position automatically, the setting method is as same as above.
Step3: After finish setting, long press the key over 5 secs to store automatically and exit, the range of power threshold is 0.0～22kW.
Application Scenarios
1. Home
Monitoring the power consumption of home device such as air conditioner, refrigerator, TV and so on, to help you save energy.
2. MNS
Industry MNS
3. Inverter
Switching power supply, heating small, can be used in inverter, SCR etc which have much interference circuit
4. Maintain
Engineering maintenance
5. Assembly Line
6. Photovoltaic System
Size Information
