Pir Infrared Motion Sensor 180 Degree 12m Distance Wall Mounted for Lights
Other recommendations for your business
Contact us
Quik Detail
| Model Number | GST09 |
|---|---|
| Type | Motion & Position Sensor |
| Place of Origin | Shanghai, China |
| Brand Name | GASIM |
| Theory | Other |
| Description | PIR Motion Sensor Switch |
| name | PIR Motion Sensor Switch |
| Detection Range | 180 degree |
| Power Source | 110-130V/AC?? 220-240V/AC |
| Power Frequency | 50/60Hz |
| Rated Load | Max. 800W (110-130V/AC),1200W (220-240V/AC), 200W (110-130V/AC |
| Motion Speed | 0.6-1.5m/s |
| Installation Height | 1.8-2.5m |
| Ambient light: | <3-2000Lux(adjustable) |
| product | 180 degree |
Product Detail
curtain pir motion sensor
| name | Motion Sensor |
| Detection Range | 180 degree |
| Power Source | 110-130V/AC?? 220-240V/AC |
| Frequency | 50/60Hz |
Application
Detection Range: 180 degree
Power Source:110-130V/AC?? 220-240V/AC
Power Frequency: 50/60Hz
Rated Load:Max. 800W (110-130V/AC),1200W (220-240V/AC), 200W (110-130V/AC),300W (220V-240V/AC
Detection Distance: max.12m (<24°C)
Time Delay:10sec ±3sec to 7min ± 2min(adjustable)
Ambient light: <3-2000Lux(adjustable)
Detection Motion Speed:0.6-1.5m/s
Installation Height:1.8-2.5m
standard export packing for Motion Sensor
The products we professionally deal with are switching power supplies, sensors, relays, voltage stabilizers, AC contactors, circuit breakers, distribution boxes, industrial plugs & sockets and others.
we are a manufacturer & exporter, we are sure that we can best support our customers with high quality products and the most competitive
Q1;WHY CHOOSE US?
1.with 20 years experience
2.high quality with fast delivery and good price
3.Rohs approval
4. samples PROVIDED
