AMEISON 2400 - 2500 + 4925 - 5925 MHz 14 dBi Directional Base Station Sector Panel Antenna dual antenna wireless wifi
Other recommendations for your business
Contact us
Quik Detail
| Model Number | AMXP-2459V-D14L90120 |
|---|---|
| Place of Origin | SHENZHEN |
| Brand Name | AMEISON |
| Frequency range(MHz) | 2400~2500/4925~5925 |
| Polarization | Vertical |
| Gain(dBi) | 2*14 |
| half-power beam width(0°) | H:90 V:15/ H:120 V:8 |
| Input connector type | 2*N-Female |
Product Detail
AMEISON 2400 - 2500 + 4925 - 5925 MHz 14 dBi Directional Base Station Sector Panel Antenna dual antenna wireless wifi
AMXP-2459V-D14L90120
Feature:
High gain
Full day working
Optimized dimension
Vertical or horizontal
Application:
2.4 GHz WLAN system
2.4GHz ISM band
Wi-Fi system
5.8 GHz WLAN system
4.9-5.9 GHz ISM band
|
AMXP-2459V-D14L90120 Electrical Specifications |
||
|
Frequency range(MHz) |
2400~2500 |
4925~5925 |
|
Polarization |
Vertical |
|
|
Gain(dBi) |
14 |
14 |
|
half-power beam width(0°) |
H:90 V:15 |
H:120 V:8 |
|
Front-to-back ratio(dB) |
≥32 |
≥32 |
|
Input Impedance(Ω) |
50 |
|
|
Sidelobe suppression for first sidelobe above horizon(dB) |
15 |
|
|
VSWR |
≤1.5 |
≤1.7 |
|
Maximum input power(W) |
200 |
100 |
|
Lightning protection |
DC Ground |
|
|
Mechanical Specifications |
||
|
Input connector type |
2xN-Female |
|
|
Dimensions-mm (Height/Width/Depth) |
1040*175*80 |
|
|
Packing size(mm) |
1100*200*150 |
|
|
Antenna weight(kg) |
6.5 |
|
|
Radome material |
UPVC |
|
|
Radome color |
Gray |
|
|
Mechanical tilt(°) |
0~15 |
|
|
Operating temperature(°c) |
-30~75 |
|
|
Rated Wind Velocity(m/s) |
60 |
|
|
Waterproof Standard |
IP67 |
|
|
Mounting way |
pole-holding |
|
|
Mounting hardware(mm) |
35 ~ 75 |
|
