Carbon Steel High Pressure Gas Storage Tank 16bar 30bar 40bar 100bar 2000L Air Storage Tank
Other recommendations for your business
OEM Carbon Steel Compressor Air Tank 22 Gallon with Drain Valve Pressure Gauge 1000L Pressure Vessel
Contact us
Quik Detail
| place of origin | Hebei, China |
|---|---|
| brand name | KEEPWIN |
| video outgoing-inspection | Provided |
| machinery test report | Provided |
| core components | PLC, Engine |
| dimension(l*w*h) | 1900*700*700mm |
| volume (m³) | 2 |
| inner material | 304 |
| outer material | 304 |
| Design Pressure (mpa) | 2Mpa |
| design standard | GB150 |
| working temperature(℃) | 30 - 145 |
| warranty | 1 Year |
| key selling points | Long Service Life, Competitive Price |
| Type | pressure tank, Vertical |
| Weight (KG) | 1000 |
| Product name | 16bar 30bar 40bar 100bar 2000L Air Storage Tank |
| Material | Carbon Steel Q345R |
| Advantage | Long Servide Life |
| Package | Wooden Case |
| Medium | N2 CO2 Gas |
| Standard | GB150-2011 / ASME Composite Autoclave |
| Working pressure | 8Bar 10Bar 16Bar 25Bar |
| After Warranty Service | Spare Parts |
| MOQ | 1 Set |
Product Detail
Carbon Steel High Pressure Gas Storage Tank 16bar 30bar 40bar 100bar 2000L Air Storage Tank
| Air Tank Technical Parameter | ||||||
| Specification | Height (H1) |
Inter Dia
|
Outlet | Safety valve interface | Sewage valve interface | |
| Volume /Pressure | DN | Screw | ||||
| 0.3/0.8 | 1594 | 550 | 65 | Rp1 1/2 | Rp3/4 | Rp1/2 |
| 0.3/1.0 | 1594 | |||||
| 0.3/1.3 | 1598 | |||||
| 0.3/1.6 | 1598 | |||||
| 0.6/0.8 | 1905 | 700 | 65 | Rp1 1/2 | Rp3/4 | Rp1/2 |
| 0.6/1.0 | 1907 | |||||
| 0.6/1.3 | 1909 | |||||
| 0.6/1.6 | 1907 | |||||
| 1.0/0.8 | 2365 | 800 | 80 | Rp1 1/2 | Rp1 | Rp1/2 |
| 1.0/1.0 | 2367 | |||||
| 1.0/1.3 | 2367 | |||||
| 1.0/1.6 | 2367 | |||||
| 1.5/0.8 | 2727 | 900 | 80 | Rp2" | Rp1 | Rp3/4 |
| 1.5/1.0 | 2729 | |||||
| 1.5/1.3 | 2727 | |||||
| 1.5/1.6 | 2731 | |||||
| 2.0/0.8 | 2782 | 1000 | 80 | Rp2" | Rp1 1/4 | Rp3/4 |
| 2.0/1.0 | 2786 | |||||
| 2.0/1.3 | 2782 | |||||
| 2.0/1.6 | 2786 | |||||
| 2.5/0.8 | 2834 | 1100 | 80 | Rp1 1/4 | Rp3/4 | |
| 2.5/1.0 | 2836 | |||||
| 2.5/1.3 | 2836 | |||||
| 2.5/1.6 | 2836 | |||||
| 3.0/0.8 | 2944 | 1200 | 100 | Rp1 1/2 | Rp3/4 | |
| 3.0/1.0 | 2946 | |||||
| 3.0/1.3 | 2946 | |||||
| 3.0/1.6 | 2980 | |||||
| 4.0/0.8 | 3056 | 1400 | 100 | Rp1 1/2 | Rp3/4 | |
| 4.0/1.0 | 3090 | |||||
| 4.0/1.3 | 3056 | |||||
| 4.0/1.6 | 3090 | |||||
| 5.0/0.8 | 3746 | 1400 | 125 | Rp2 | Rp1 | |
| 5.0/1.0 | 3780 | |||||
| 5.0/1.3 | 3746 | |||||
| 5.0/1.6 | 3780 | |||||
Related Product
Diaphragm Compressor
Features of products:
1. Compressed gas is completely sealed from outside, which provides high sealing performance; the compressor of high sealing performance is specially suitable for use to compress gas in radioactive area of nuclear power plant and highly poisonous gas;
2. Owing to nonexistence of lubricant in diaphragm cavity, namely it is impossible for gas to contact any lubricant, there is no problem to compress to higher pressure the dangerous gas and oxygen, fluorinated gas and chlorine, etc;
3. Compared to the compressors of other types, gas will not be polluted by the particles produced due to abrasion of sliding parts, therefore, it is absolutely ensured the same purity of compressed gas as that of the gas when entering compressor. Therefore, it is suitable for high purity gas such as electronic gas, breathing gas and hydrogen used in fuel cell technology;
4.Diaphragm alarm device and low-pressure alarm of lubricating oil ensure safety and reliability of operation of compressor;
Professional Engineers Design team & Professional technical communication before production, create and produce high quality oil-free Diaphragm comrpessor, Reciprocating compressor
Confirmed all detail specificaitions with the Customers then sign contract, design drawing in process to ensure every process is perfect. High flow rate and manufacture machine qualified test before shipment.
Q1. What is your terms of packing?
A: Generally, we pack our goods in neutral white boxes and brown cartons. If you have legally registered patent,
we can pack the goods in your branded boxes after getting your authorization letters.
Q2. What is your terms of payment?
A: T/T 50% as deposit, and 50% before delivery. We'll show you the photos of the products and packages
before you pay the balance.
Q3. What is your terms of delivery?
A: EXW, FOB, CFR, CIF, You can choose the one which is the most convenient or cost effective for you.
Q4. How about your delivery time?
A: Generally, it will take 5 to 7 days after receiving your advance payment. The specific delivery time depends
on the items and the quantity of your order.
Q5. Can you produce according to the samples?
A: Yes, we can produce by your samples or technical drawings. We have a professional team having rich experience in air compressor parts design and manufacturing. Just tell us your ideas and we will help to carry out your ideas into perfect product. It does not matter if you have the part No. or not. Send us drawing pictures or specifications, we'll customize it for you.
Q6. How can I get a sample to check your quality?
After price confirmation, you can require for samples to check our quality.
If you need the samples, we will charge for the sample cost .But the sample cost can be refundable after order confirmation when your quantity of the order is more about the MOQ.
Q7. Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery
Q8: How do you make our business long-term and good relationship?
A:1. We keep good quality and competitive price to ensure our customers benefit ;
2. We respect every customer as our friend and we sincerely do business and make friends with them,
no matter where they come from.
For More gas compressor and pressure vessel inquiry, please kindly chat us online direct, our sales will reply you within 2hours.
Send your Inquiry Details specifications as the Below required:
Clients' inquiries should contain related parameters
A. The gas compression medium
B. The flow rate: _____Nm3/hr
C. Inlet pressure: _____ Bar
D. Discharge pressure: _____ Bar
E. Inlet temperature
F. Cooling water temperature as well as other technical requirement.
