High Quality 3-9th Gen I3 I5 I7 OPS Mini PC Durable Memory School Office Education Solution Smart Computer Accessory
US $99.00-119.00 / piece
100 piece(s)Minimum order
products status:
Stock
type:
OPS computer
brand name:
aio
place of origin:
Guangdong, China
Processor Brand:
Intel
Type:
education pc
Privacy Policy:
Samples are free within a certain price range
Other recommendations for your business
$100.00-300.00
100 pieces (MOQ) Contact us
Quik Detail
| products status | Stock |
|---|---|
| type | OPS computer |
| brand name | aio |
| place of origin | Guangdong, China |
| Processor Brand | Intel |
| Type | education pc |
| Size | 195 x 180 x 30 mm |
| Color | black |
| Shell material | Sheet metal |
| Net weight | 1kg |
| Working temperature | -20°c~70°C |
| Working humidity | 10%~90% |
Product Detail
Product Description
Intel® OPS-C Standard Module
6-9 TH Generation Intel® Core™ Processors
4K/60Hz, HDCP v2.2
Dual Channel DDR4 Memory
M.2 2280 SATA / NVMe SSD
Remote Wake-on-LAN function
Timed startup, restore backup, PXE
6-9 TH Generation Intel® Core™ Processors
4K/60Hz, HDCP v2.2
Dual Channel DDR4 Memory
M.2 2280 SATA / NVMe SSD
Remote Wake-on-LAN function
Timed startup, restore backup, PXE
Specification
CPU | Intel® Coffeelake/Kabylake-SLGA1151 processor |
Chipset | Intel® H310C |
Memory | 2 x SO-DIMM DDR4 Max. 64G |
Storage | 1 x M.2 2280 SATA SSD 1 x M.2 2280 SATA/ NVMe SSD |
Graphic | Intel® UHD Graphics |
Wireless | 1 x M.2 2230 PCIE, WIFI/BT Module |
Ethernet | Gigabit Ethernet |
Audio | Realtek ALC269 HD Audio |
Front I/O | 1 x Power LED 1 x HDD LED 2 x USB 2.0 Type-A 4 x USB 3.0 Type-A 1 x USB 3.0 Type-C 1 x RJ45 1000M 1 x 3.5mm Line out 1 x 3.5mm Mic in 1 x HDMI 2.0 1 x System recovery 1 x DP1.4 1 x Reset /CL CMOS button 1 x Power button 2 x ANT |
Rear 80-pin | HDMI2.0，2 x USB2.0 , 1 x USB3.0，UART，Audio，Recovery，etc |
Power | 12-19V DC IN Min.90W |
Dimension | 195 x 180 x 30 mm |
OS | Windows 10/11/LINUX |
Operation Temperature | Operating -10℃~50℃ Storage -20℃~70℃ 10%~90% （non-condensing） |
Manufacturing & Quality Control
Ops Manufacturing capacity.
Production equipment: 3*20m standard assembly lines, 13*product test stands, 6 *aging racks and 2 packaging lines. Production personnel: production personnel * 3 groups, QC personnel * 1 group, maintaine * 1 group, Production engineering * 1 group. Manufacturing system: Manufacturing
system: MES, ISO9001, IE, lean production. Daily output: 1000 standard parts/day，Max 120%.
Quality reliability test
High&Low temperature test
simulate vibration test
BGA welding analysis
Aging test
EMC&ESD test
Heat dissipation test
Power adaptability test
Wireless transmission test
l/0 plug fatigue test
Quality control flow chart
Product Application
The OPS computer is a Pluggable OPS computer based on Intel OPS(Open Pluggable Specification) solution. The product is widely used in multimedia teaching system,computer touch all-in-one, digital signage.
Packaging logistics
Packaging : We carefully wrapped OPS computers and components in antistatic bags, and then fixed them in inner boxes with EPE pearl cotton protective covers. Put 5 inner boxes into the outer box, and then seal the outer box with adhesive tape.
Packing list : OPS PC*1 Antenna *2 Do not loosen screws *2
Shipping Methods.
Shipping by DHL, Fedex, Aramex, post and Alibaba, RETS Express and negotiation. ( choose as you prefer).
Freight calculation reference:
1 piece/independent carton (average:1.0-1.5kg,Meas:27.5*23*10cm);5 pieces/standard independent carton (g.w:5.6-8kg,Meas:47*28*24.5cm)5 pieces/standard 5-in-1pack carton (g.w:5.0-7.7kg,.Meas::32*27.8*26.5cm);
FAQ
Q1: What types of large display are compatible with your OPS PC?
A: Our OPS PC is designed according to the standard Intel OPS protocol. As long as the large screen conforming to the OPS protocol can be matched. According to statistics, 95% of the OPS slots and 80pin definitions of large screens in the market comply with Intel OPS protocol and are fully compatible. Compatible manufacturers include Samsung LG Philips AOC BenQ hitevision Hisense konna change Skyworth TCL KCT iboard riotouch Deli ipboard boct Qinguan JAV hushida maxhub sosu w-media, etc. incompatible manufacturers include cvte seewo ViewSonic (some models). You can also tell me the model of the large screen.
Q2: How to adapt the best OPS computer according to the large screen?
A: The selection of OPS PC configuration is calculated according to specific use requirements and scenarios. The OPS size is determined according to the measured large screen OPS slot size. You can inform the customer service of the demand and the approximate size of large screen OPS, and professional engineers will serve you. Ops has three conventional sizes: 180 * 195 * 42cm, 180 * 195 * 30cm and 180 * 119 * 30cm.
Q3: What configuration options do you have for your OPS?
A: Ops size: 180 * 195 * 42cm, 180 * 195 * 33cm, 180 * 195 * 30cm, 180 * 119 * 30cm, customized size. Appearance color: black, white, custom color CPU: Intel 3rd-11th, atom Celeron Pentium I3 i5 i7 i9 RAM: DDR3/4/5,4G-64G Hard disk: SSD / HDD, 64g-10t, SATA, msata, ngff PCIe Graphics card: integrated graphics card / independent graphics card Display output: 2K / 4K / 8K, 30Hz / 60Hz / 120Hz, VGA / DVI / HDMI / DP I/O : USB2.0/3.0,TYPC/HDMI VGA DP/audio/LAN/COM Network: WiFi / BT / 4G / 5G
Q4: Can OPS PC be operated on the large screen?
A: Of course, it supports the operation of OPS computer on the large screen, such as startup and shutdown, touch port call, etc..
Q5: Support os one click restore and backup?
A: Of course, most models of our OPS PCs have hardware ghost function and support one click restore.
Q6: Do you support OEM / ODM?
A: Of course, we support OEM/ODM service. service content: OEM 1. logo printing on housing 2. Customize package 3. Software Customization: Booting image, UI, APP, Function… and so on ODM 1. PCBA desgin 2. Housing desgin 3. Software Customization: Booting image, UI, APP, Function… and so on
Q7: How much do I need to pay for your OEM/ODM service?
A: There is no extra charge for simple Oems, special Oems and simple ODMs are charged at cost, generally not more than $500, but if you order 300 units per lot, it will be Free for oem. Special ODMS are charged at cost, but if your order reaches 500 per lot, it will be Free.
Q8:What is the price base?
A: Our price is based on detailed specification such as RAM, HD/SSD, WIFI card, etc. The price range on Alibaba basically covers all specification, so pls contact us first with your detailed specification before your order release.
Q9: What is the minimum order quantity?(MOQ)
A: 1 unit
Q10: What trade terms do you accept?
A: EX-W/FOB/CIF all can accept.
Q11: What is your warranty and after-sales policy?
A: The defect rate of our OPS computers is lower than 0.3% The general warranty period is 3 years. The product adopts modular design, during the warranty period of failure and repair, we will quickly send spare parts in the past to replace, if necessary can also recall.
Q12: How long the package will ready after I buy the OPS pc?
A: mainboard Under normal inventory conditions, 50 units can be delivered within 24 hours, and 200 units can be delivered within 48 hours. Please consult us for more information.
Q13: Are your mini pc in stock?
A:Yes, most of our models are in stock. You can confirm model with us before placing your order.
