High Quality Cnaom Flat Head Switch Without Light on off Switch Push Button Switch
US $0.38-0.42 / piece
10 piece(s)Minimum order
Whether the smart:
NO
Place of Origin:
Zhejiang, China
Brand Name:
CNAOM
Model Number:
LA38-11ZS lock
Max. Current:
Less than 10A
Max. Voltage:
440V
Privacy Policy:
Samples are free within a certain price range
Other recommendations for your business
$0.66-0.69
10 pieces (MOQ)
$0.44-0.47
10 pieces (MOQ)
$17.79-18.60
5 pieces (MOQ)
$12.94-13.53
5 pieces (MOQ)
$0.52-0.56
10 pieces (MOQ)
$0.52-0.56
10 pieces (MOQ)
Contact us
Quik Detail
| Whether the smart | NO |
|---|---|
| Place of Origin | Zhejiang, China |
| Brand Name | CNAOM |
| Model Number | LA38-11ZS lock |
| Max. Current | Less than 10A |
| Max. Voltage | 440V |
| LED | NO |
| Color | Red |
| Product name | Push button Switch |
| Hole size | 22MM |
| Mechanical life | More than 500 thousand times |
| Contact | 1NO 1NC |
| contact Material | copper |
| Type | self locking |
| Protection Level | A |
| Certification | CCC |
Product Detail
Product Description
Cnaom high Sensitive contact 22MM Push Button Switches
Push button switch refers to the switch that uses the button to push the transmission mechanism, make the moving contact and the static contact press on or off, and realize the circuit switching. In the electrical automatic control circuit, it is used to manually send control signals to control contactors, relays, electromagnetic starters, etc.
The Push button switch can complete the start, stop, positive and negative rotation, speed change and interlock and other basic control. Usually each push button switch has two pairs of contacts. Each pair of contacts consists of a normally open contact and a normally closed contact. When the button is pressed, the two pairs of contacts act at the same time, the normally closed contact is disconnected, the normally open contact is closed.
Specification
Model | LA38-11ZS |
Dimensions of thread openings | 22MM |
Current | Less than 10A |
Contact | 1NO 1NC |
Contact material | Copper |
Voltage | 440V |
Button type | Self-locking |
Product dimensions | 32*80mm |
Packing & Delivery
Packing | inner box | carton | |
10PCS | 500PCS | ||
Carton size | 50.5*33.5*43.5CM 26KGS | ||
Delivery | <1000 | >1000 | |
within a week | It depends on the quantity | ||
Note:The delivery time is for reference only,please confirm with the seller for details.
Installation Instructions
Company Profile
FAQ
1. Are you a factory?
We are the manufacturer of limit switch,micro switch,foot switch and so on.
2. how do you control the quality of the products?
We will perform 100% machine inspected before packaging.
3. would you accept use our logo?
Yes,of course.But the quantity should be more than 20000pcs,we can make OEM,ODM.
4. how long is the delivery time?
It depends on your quantity.
For samples or small quantity,we promise to sent in 1~5 days.Most have in stock.
For mass production, such like 20FT container we promise to sent in 15-30 days.
5.Which shipping method do you provide?
For samples or small orders, goods will be sent by express.
For regular orders, goods can be sent by air or by sea, just according to your demand.
6. How can we get the samples?Is it free?
We provide free samples by express, but you need pay the express charge or make samples collection at your side.
We are the manufacturer of limit switch,micro switch,foot switch and so on.
2. how do you control the quality of the products?
We will perform 100% machine inspected before packaging.
3. would you accept use our logo?
Yes,of course.But the quantity should be more than 20000pcs,we can make OEM,ODM.
4. how long is the delivery time?
It depends on your quantity.
For samples or small quantity,we promise to sent in 1~5 days.Most have in stock.
For mass production, such like 20FT container we promise to sent in 15-30 days.
5.Which shipping method do you provide?
For samples or small orders, goods will be sent by express.
For regular orders, goods can be sent by air or by sea, just according to your demand.
6. How can we get the samples?Is it free?
We provide free samples by express, but you need pay the express charge or make samples collection at your side.
