Pneumatic Automatic Plastic Loader Vacuum Loader Resin Feeder Hopper Auto Loader Transport Machine
1 piece(s)Minimum order
place of origin:
Guangdong, China
Capacity (kg/h):
1600
video outgoing-inspection:
Provided
machinery test report:
Provided
core components:
PLC, Engine, Bearing, Gearbox, Pressure vessel, Gear, Pump
brand name:
Liansu-Mconvey
Privacy Policy:
Samples are free within a certain price range
Other recommendations for your business
$170.00-2,500.00
1 piece (MOQ)
$200.00-1,900.00
1 set (MOQ)
$160.00-1,450.00
1 piece (MOQ)
$79,500.00-80,000.00
1 piece (MOQ)
Contact us
Quik Detail
| place of origin | Guangdong, China |
|---|---|
| Capacity (kg/h) | 1600 |
| video outgoing-inspection | Provided |
| machinery test report | Provided |
| core components | PLC, Engine, Bearing, Gearbox, Pressure vessel, Gear, Pump |
| brand name | Liansu-Mconvey |
| voltage | customized |
| dimension(l*w*h) | 1660*400*520mm |
| warranty | 18 months |
| weight (kg) | 159 |
| power (kw) | 3.75 |
| Size | 1660*400*520mm |
| color | body white,frame light blue, body white, frame black |
| Material | 304 Stsainless Steel |
| Certification | ce ISO |
| After sales Service Provided | Free spare parts, Video technical support |
| After Warranty Service | Video technical support, Field maintenance and repair service |
| Local Service Location | Egypt/Chile |
| Marketing Type | New Product 2020 |
Product Detail
提示信息
Subtitle/CC
Speed
Quality
Audio Track
Speed
Subtitle/CC
Audio Track
Quality
Features:
* With a lower suction design, it has a cyclone baffle and separate dust bucket under the filter, which can effectively reduce the load of the filter;
* Separate dust bucket for easy dust removal;
* With the electrical control function of the two-ingredient proportional valve, it can be directly equipped with a two-ingredient proportional valve;
* The hopper loaders above 5HP are equipped with a vacuum breaking valve, which can effectively increase the suction capacity;
* The main machine is equipped with fault and motor overload indicator lights, which can give an alarm quickly;
* The central operation panel can be used to centrally set the suction parameters of each station;
* The main machine is equipped with a suction overtime and fan overload alarm device.
Scope of application:
* Providing high-pressure vacuum (negative pressure) power, it is mainly used in the central feeding system or single-machine feeding applications. The start of the fan in the central feeding system can be connected to and controlled by the centralized control station;
* It can be used together with different types of hopper loaders based on customer needs to meet the feeding and conveying of granules and powder;
* The suction mode of the feeding system can be equipped with a hopper loader to form a feeding loop.
Schematic diagram:
Specification table:
Model | High pressure fan power (KW) | Conveying capacity (kg/h) | Hopper capacity (L) | Air suction port diameter (mm) | Material suction port diameter (mm) | Voltage | ||||||
LSAL-2HP-UG | 1.5 | 500 | 12 | 38 | 38 | 3¢, 400V, 50Hz | ||||||
LSAL-5HP-UG | 3.75 | 1000 | 25 | 50.8 | 50.8 | 3¢, 400V, 50Hz | ||||||
LSAL-10HP-UG | 7.5 | 1600 | 50 | 63 | 63 | 3¢, 400V, 50Hz | ||||||
LSAL-5HP-UG-2 | 3.75 | 1000 | 25 | 50.8 | 50.8 | 3¢, 400V, 50Hz | ||||||
LSAL-10HP-UG-2 | 7.5 | 1600 | 50 | 63 | 63 | 3¢, 400V, 50Hz | ||||||
LSAL-5HP-UG-4 | 3.75 | 1000 | 25 | 50.8 | 50.8 | 3¢, 400V, 50Hz | ||||||
LSAL-10HP-UG-4 | 7.5 | 1600 | 50 | 63 | 63 | 3¢, 400V, 50Hz | ||||||
Conveying capacity reference: horizontal - 4 meters, vertical - 4 meters, raw material - ABS granules; bulk density - 0.65kg/L | ||||||||||||
Product Display
