Pneumatic Stainless Steel Wafer Butterfly Valve Bray Butterfly Valve
Other recommendations for your business
Contact us
Quik Detail
| application | General |
|---|---|
| port size | DN20-DN300mm |
| warranty | 1 years |
| place of origin | Shanghai, China |
| model number | DN20-DN300 |
| power | Manual |
| temperature of media | High Temperature, Low Temperature, Medium Temperature |
| brand name | Yimake |
| structure | BUTTERFLY |
| media | Water |
| customized support | OEM, ODM, OBM |
| Seat | NBR, EPDM, Neoprene, PTFE, BUNA, Hypalon. |
| Body/Disc | Cast Iron(CI): GG25,Ductile Iron(DI):GGG50 |
| Suitable medium | Petroleum, chemical industry, water, oil, gas etc. |
| Size Range | 2"~28", DN50~DN700 |
| Acting Mode | Double Acting, Spring Return (Single Acting) |
| Optional Accessories | Namur Solenoid Valve, Limit Switch, F.R.L, Position Indicator |
| Body material | SS304, SS316, SS316L |
| Actuation Time | 1~2 seconds at 8.0 Bar Air Pressure |
| Angle of Rotation | 90° ±4° |
| Type | Butterfly Valves |
Product Detail
| Size Range | 2"~28", DN50~DN700 |
| Acting Mode | Double Acting, Spring Return (Single Acting) |
| Operating Pressure | 1.6MPa |
| Air Supply Pressure | 2.5 to 8 bar |
| Angle of Rotation | 90° ±4° |
| Actuation Time | 1~2 seconds at 8.0 Bar Air Pressure |
| Body Material | SS304, SS316, SS316L |
| Applicable Media | Control of Water, Air, Gas, Oil, Liquid |
| Application | Water & Wastewater, Ultra Pure Water, Desalination, Chemical, Textile, Pharmaceutical, Pulp & Paper |
| Optional Accessories | Namur Solenoid Valve, Limit Switch, F.R.L, Position Indicator, Manual Device |
1. Are you manufacturer or trading company?
We are the manufacturer. Our factory is located in Fengxian District, Shang Hai, China. You are welcome to check our factory via Video Call or visiting on site or by third party organization such like SGS or TUV.
2. Is your price competitive compared with other companies?
Yes for sure. Our business targets are to offer win-win price and reliable aftersale service. We always do our best to help in reducing your cost and enhance your competitive ability in local market. Our team will supply customized sale solution according your markets situation. Completely distributors system and OEM system will save you more.
3.Delivery time.
Within 7-15 days for Customized products. Available products in stock are shipped the 3 days after correct packing.
4. How to guarantee the quality of your products?
You are welcomed to send an inspector, not only for the container loading, but any time during the production time. We can also offer QC test report as per your needs. Except consumption parts all products has at least 1 year warranty after delivery from factory. If defect reason caused by quality, we can change it for free charges, if defect reason caused by non standard operation, we can help to find the reason and help in offering more suitable specification and replacement.
