Stainless Steel Netzsch Slurry Cement Grout Grease Small Mortar Seepex Screw Pump
Other recommendations for your business
Contact us
Quik Detail
| warranty | 1 year |
|---|---|
| customized support | OEM, ODM, OBM |
| brand name | LENO |
| model number | LNP-3009 |
| place of origin | Zhejiang, China |
| application | Food and Beverage Industry |
| horsepower | 1.5HP |
| power source | Electric |
| pressure | 8BAR |
| structure | SCREW PUMP |
| outlet size | 2 inch |
| voltage | 110V-480V |
| power | 1.5KW |
| Product name | stainless steel food grade mono screw pump |
| Material | SS304/316L |
| Type | SCREW |
| Speed | 0-960RPM |
| Frequency | 50 /60 Hz |
| Seal | EPDM/SILICON/PTFE |
| Motor | ABB/SIEMENZ/Dosmetic |
| Flow | 0-100TON/H |
| Usage | TRANSFER HIGH VISCOSITY LIQUID |
| Application | Transferring |
| Certification | ce |
Product Detail
| Profile/type |
STAINLESS STEEL MONO SCREW PUMP |
||
| material | SS304 or SS316L | ||
| Capacity | 0-100T (Customized) | ||
| Pressure | 0-8bar | ||
| High Viscosity | 1-100,000,00pas | ||
| Stator type | Rubber type | ||
| temperature | 0-80 celsius degree | ||
| connection type | Clamp | Union | Flange |
| motor type | Normal | Ex-Proof | inverter |
| motor cover | Round/Square | ||
| Speed |
0-960RPM |
||
1.outlet 2.pulling 3.stator 4.screw shaft 5.cardan joint 6.inlet 7.coupling 8.feeding foundation 9.feeding bid
10.bearing pedestal 11.shaft 12.auxiliary 13.bearing bid 14.shaft coupling 15.foundation 16.motor
Application:
Screw pump rotor for food industry is also called progressive cavity pump, Is widely used in
delivery of high viscosity products such as chocolate, syrup and jams etc.
| Technical Parameters | ||||
| Model | FLOW(T/H) | Lift(M) | Speed(RPM) | Motor(KW) |
| LNP-10-M | 0.5 | 0-8bar | 1400 | 0.37 |
| LNP-15-M | 1 | 0-8bar | 960 | 0.55 |
| LNP-20-M | 1.5 | 0-8bar | 960 | 0.75 |
| LNP-25-M | 2 | 0-8bar | 960 | 1.1 |
| LNP-30-M | 3 | 0-8bar | 960 | 1.5 |
| LNP-35-M | 5 | 0-8bar | 960 | 2.2 |
| LNP-40-M | 7 | 0-8bar | 960 | 3 |
| 5.5 | 0-8bar | 720 | 2.2 | |
| LNP-45-M | 9 | 0-8bar | 960 | 4 |
| 7 | 0-8bar | 720 | 3 | |
| LNP-50-M | 13 | 0-8bar | 960 | 5.5 |
| 10 | 0-8bar | 720 | 4 | |
| LNP-55-M | 18 | 0-8bar | 960 | 7.5 |
| 13 | 0-8bar | 720 | 5.5 | |
|
LNP-65-M |
30 | 0-8bar | 720 | 11 |
| LNP-85-M | 60 | 0-8bar | 720 | 15 |
| We Can Customize The Equipment According To Your Requirements. | ||||
| Q1 | Are you trade or manufacturer? |
| A |
We are a factory with an international sales company specialized in support for global distributors. |
| Q2 | Can you provide instant technical consulting services? |
| A | We are able to discuss technical details and offer suggestions over the phone in English. You can get the answers in minutes, instead of days. |
| Q3 |
What's the difference between Ready-To-Ship and Customized products? |
| A |
Some of RTS standard products are in stock and ready to ship in 2-3 days. |
| Q4 | What is the payment terms? |
| A |
We accept Alibaba Trade Assurance Order, also can T/T and L/C. |
| Q5 | How to choose the shipment way? |
| A |
It is according to the order quantity, delivery time, costs and customs policy etc. (Or decide by customers) |
| Q6 |
How about the after-sales service? |
| A | Fast after-sales support. Our products have a one-year warranty and free permanent consulting services. |
