Supmea Industrial Non Contact 0-15m Water Ultrasonic Level Meter Sensor Level Transmitter
US $225.00-245.00 / piece
2 piece(s)Minimum order
warranty:
12 months
customized support:
OEM
place of origin:
Zhejiang, China
brand name:
Supmea
material:
Plastic
Accuracy:
±0.5, ±0.5% FS (optional ± 0.2% FS)
Privacy Policy:
Samples are free within a certain price range
Other recommendations for your business
$490.00-515.00
1 piece (MOQ)
$185.00-200.00
2 pieces (MOQ)
$39.00-69.00
1 piece (MOQ)
$150.00-245.00
2 pieces (MOQ) Contact us
Quik Detail
| warranty | 12 months |
|---|---|
| customized support | OEM |
| place of origin | Zhejiang, China |
| brand name | Supmea |
| material | Plastic |
| Accuracy | ±0.5, ±0.5% FS (optional ± 0.2% FS) |
| Product name | Ultrasonic Level Sensor |
| Installation method | Threaded mounting/flange mounting |
| Ingress protection | IP65 |
| Measuring range | 0~5M/ 0~10M/ 0~15M/ 0~20M/ 0~30M |
| Resolution | 1mm or 0.1%FS (maximum) |
| Ambient temperature | 0~50℃ |
| Current output | 4~20mA |
| Communication | Isolated RS485 Modbus-RTU Communication Protocol (Optional) |
| Power supply | 14~28VDC 85~305VAC,5W Max,50/60Hz (optional) |
Product Detail
Products Description
Display | 2-inch black and white LCD with 128*64 resolution |
Installation method | Threaded mounting/flange mounting |
Ingress protection | IP65 |
Measuring variable | Level / Distance |
Measuring range | 0~5M/ 0~10M/ 0~15M/ 0~20M/ 0~30M |
Accuracy | ±0.5% FS (optional ± 0.2% FS) |
Resolution | 1mm or 0.1%FS (maximum) |
Temperature compensation | Automatic temperature compensation with temperature calibration function |
Ambient temperature | 0~50℃ |
Storage temperature | -20~70℃ |
Relative humidity | (10~85)%RH (no condensation) |
Current output | 4 ~ 20mA can set the measuring range of corresponding object position/distance, the maximum load is 500Ω, and the output accuracy is 0.2%FS |
Communication | Isolated RS485 Modbus-RTU Communication Protocol (Optional) |
Relay output | Two independent normally open contacts with high/low setting (Hi/Lo) and 250VAC 3A Max contact capacity (optional) |
Power supply | 14~28VDC |
85~305VAC，5W Max，50/60Hz (optional) |
