Waterproof E-stop Switch 1NC Push Button Switch Box Emergency Stop Push Button Mushroom Switch Control Station

US $0.59-1.39 / piece
5 piece(s)Minimum order
Application:
Industrial Control, Electric, latching
Material:
Plastic
Structure:
Mechanical
Terminal Type:
Screw Terminal
Whether the smart:
Yes
Place of Origin:
Zhejiang, China
Privacy Policy: Samples are free within a certain price range

Contact us

Send Inquiry

Quik Detail

Application

Industrial Control, Electric, latching

Material

Plastic

Structure

Mechanical

Terminal Type

Screw Terminal

Whether the smart

Yes

Place of Origin

Zhejiang, China

Brand Name

xindali

Model Number

XDL25-J174H29

Max. Current

10A

Max. Voltage

380v

LED

NO

IP level

ip65

Switch Combination

1NO1NC, 1NO, 2NO2NC, 2NO, 1NC

Contact

N/C

IP Grade

IP65/ip54

Certificate

CE

Certification

CE

Product Detail

Product Description
1 Operational temperation:-5°c - +40°c the average value less than +35°c in 24 hours
2 Altitude: less than 2000m
3 Atmosphere condition : when the maximum temperature is +40 °c ,the Operational humidity is less than 50%,allow higher humidity in cooler environments.
4 Pollution degree:3 level
5 Installs Category: II
6 No significant Shaking,no impact vibration and no snow or rain
7 No explosive media,the Gas and dust can't corroding metal and damage the insulation

Specifications:

1) Ambient temperature: -25~70Centigrade
2) Rated insulation voltage: UI=500V
3) Pollution class: III
4) Degree of protection: IP65/IP66
5) Altitude above sea level: <2, 000m
6) Meets IEC60947-5-1, EN60947-5-1
Product Name
holes control switch pushbutton box
Material
nylon plastic
Color
grey, black,yellow. Other color, pls inquiry.
Standard
nitrile rubber(NBR)
Grade
1)quiescent state -40 °C to 100 °C ,short time 120 °C
2)dynamic state:-20 °C to 80 °C ,short time to 100 °C .V2(UL94), free of halogen
Thread
PG,M,PG-length,NPT,MG
Used
building industry machinery
Product Show
Use environment
Why Choose Us
What is your MOQ? MOV?
We don’t have MOQ for the standard items. And the MOV for the terms of FOB is 5000USD.

What are your terms of payment?
We accept T/T, L/C payment.

Can I pay by PAYPAL?
Yes, our Paypal account is “sales@xindali.com”

How long is the delivery date?

The standard lead time 2 weeks.

What certifications does this product have?
We have CE, Rohs, UL and TUV approvals.

Are you a manufacturer? Where is the factory?
Yes, we are manufacturer, our factory located in Wenzhou.

Can you do OEM?
Yes, we can offer customized service under OEM.

Why your price is higher than others?
If we are talking about the same qualitiy level, our price will be competitve.

How long is the guarantee of your products?
We have 5 years guarantee.

Do you have water-proof items?
Yes, our XDL22 and XDL722 series are IP65.

Can you provide me with samples for free?
Yes, the samples can be offered as free of charge.

Can you provide certificate of origin?
Yes, we can.

Can you customize the product for me?
Yes, we have our own R&D team and tool centre to make customized products.

Does Xindali have agent?
Yes, we have agent of Xindali brand in Italy, Sweden, Norway, Finland, Russia, Greece, Spain and UK.

What support can I get if I become your agent?
If you will be our agent, you will get the following VIP service,
* Professinal Technical support from Xindali Team
* Special Price support
* Lead Time support
* Samples boards support
* Payment support
