42W 1050ma 48W 600ma 50W 700ma LED Panel Light Drivers Flicker Free Indoor Down Light Use
US $1.81-2.05 / piece
100 piece(s)Minimum order
Warranty(Year):
2-Year
Lighting solutions service:
Lighting and circuitry design
Place of Origin:
Guangdong, China
Brand Name:
SOLUXLED
Model Number:
HG-PC-D240
Output Power:
48W/50W
Privacy Policy:
Samples are free within a certain price range
Other recommendations for your business
$0.76-0.83
100 pieces (MOQ)
$1.94-2.14
100 pieces (MOQ)
$4.15-4.69
50 pieces (MOQ)
$3.30-3.60
300 pieces (MOQ) Contact us
Quik Detail
| Warranty(Year) | 2-Year |
|---|---|
| Lighting solutions service | Lighting and circuitry design |
| Place of Origin | Guangdong, China |
| Brand Name | SOLUXLED |
| Model Number | HG-PC-D240 |
| Output Power | 48W/50W |
| Output Type | Single Phase |
| Input Voltage | AC100-260V |
| Output Frequency | 50/60Hz |
| Output Current | 580mA/1400mA |
| Application | Panel light |
| Type | Consant Current |
| Efficiency | >90% |
| Warranty | 2years |
| Size | L110*W42*H28mm |
| Protection | Short Circuit Over Load |
| Working temperature | -30~+70℃ |
| Working Humidity | 20 ~ 95% RH Non-condensing |
Product Detail
Product Paramenters
MODEL | HG-PC-D240-600 | HG-PC-D240-1050 | HG-PC-D240-1400 | |||
OUTPUT | DC VOLTAGE | DC80V | DC40V | DC33V | ||
CONSTANT CURRENT REGION | 600mA±5% | 1050ma+-5% | 1500mA±5% | |||
RATED CURRENT | 580ma | 1050ma | 1400ma-1500ma | |||
RATED POWER | 18-24*3W | 42W | 50W 10s5p | |||
VOLTAGE ADJ.RANGE | DC54-84V | DC24-42V | DC25-36V | |||
INPUT | VOLTAGE RANGE | AC100-260V | ||||
FREQUENCY RANGE | 47-63Hz | |||||
POWER FACTOR(Typ.) | 0.5 | |||||
EFFICIENCY(Typ.) | 0.88 | |||||
AC CURRENT | <0.5A | |||||
PROTECTION | SHORT CIRCUIT | Hiccup mode, recovers automatically after fault condition is removed. | ||||
OVER LOAD | Protection type: Shut down o/p voltage, re-power on to recover | |||||
Function | Dimmable Function | Non | ||||
OTHERS | DIMENSION | 105*47*30.5mm | ||||
PACKING | 100g/pcs | |||||
WORKING TEMP. | -30~+70℃ | |||||
WORKING HUMIDITY | 20~50% RH non-condensing | |||||
Detailed images
LED Driver Power supply IP20 , application : LED donw light , LED panel light, LED indoor lighting etc.
Related Products
Company Introduction
SOLUXLED industrial is a wholesale company that manufactures LED driver Constant current & led driver constant voltage and led lightings etc, starting from 2008. The company provides the customized products and OEM service, offer led lighting solutions, millions products sold to different counries in the world.
Our Advantages
Customer's ODM customized solution Case.
led driver constant current 45W & 90W for led street light built-in driver , customized dimension for put inside the housing,customized temperature control is required, EMC, 0% ripple with double stage power factor correction design etc.
