Three Pulley Cable micro Tension Sensor , Yarn Metal Wire Rope Weight Force Sensors with 50N 100N 500N 1000N 2000N
2 piece(s)Minimum order
Series:
tension sensor
Features:
Appearance is small, high precision, easy to use
Mounting Type:
Fixed installation
Description:
The tension measuring, micro tension sensor, tension sensor
Model Number:
ESMZL-3
Type:
force sensor
Privacy Policy:
Samples are free within a certain price range
Other recommendations for your business
$30.00-86.00
2 pieces (MOQ)
$5.00-30.00
1 piece (MOQ)
$30.00-160.00
2 pieces (MOQ) Contact us
Quik Detail
| Series | tension sensor |
|---|---|
| Features | Appearance is small, high precision, easy to use |
| Mounting Type | Fixed installation |
| Description | The tension measuring, micro tension sensor, tension sensor |
| Model Number | ESMZL-3 |
| Type | force sensor |
| Place of Origin | Shaanxi, China |
| Brand Name | kexlimice |
| Use | tension measurement |
| Theory | Resistance Sensor |
| Output | mv |
| Name | ESMZL-3 yarn wire rope tape tension sensor |
| range | 0~50N,100N,500N,1000N,2000N |
| Sensitivity | 1-2.0 mv/V |
| Working temperature | -20°C ~70°C |
| Accuracy | 0.05 %FS |
| Allow over load | 150%F.S |
| Excitation voltage | 9 ~ 15 VDC |
| Sealing rate | IP67 |
| Material: | alloy steel |
Product Detail
Product Description
ESMZL-3 Suitable for tension measurement of various optical fibers, yarns, chemical fibers, wires, wires, cables, tapes, and
steel strips. Widely used in electronics, chemical, textile, paper, machinery and other fields. High precision, low drift,
hand-held, compact structure, reliable sealing, easy installation
steel strips. Widely used in electronics, chemical, textile, paper, machinery and other fields. High precision, low drift,
hand-held, compact structure, reliable sealing, easy installation
Specification
item | value | ||
Model Number | ESMZL-3 | ||
Type | force sensor | ||
Place of Origin | China | ||
Shaanxi | |||
Brand Name | kexlimice | ||
Name | ESMZL-3 yarn wire rope tape tension sensor | ||
range | 0~50N,100N,500N,1000N,2000N | ||
Sensitivity | 1-2.0 mv/V | 0~5V,1~5V,0~10mA,4~20mA | |
Non-linear: | 0.03F·S | 0.1, 0.3% F·S | |
After lag: | 0.03%F·S | 0.1, 0.3% F·S | |
Non-repetition: | 0.03%F·S | 0.1, 0.3% F·S | |
Warm drift: | 0.003%F·S/°C | 0.01, 0.03 % F·S/°C | |
Zero output: | ≤2% F·S | ≤2% F·S | |
Excitation voltage: | 10V | 12V,15V,24V(DC) | |
output signal: | Mv | 0-5V 0-10V 0-10mA 4-20mA | |
Operating temperature: | -20~80°C | ||
Overload capability: | 150%F.S | ||
Material: | alloy steel | ||
Packing & Delivery
Standard packing/as customer request
Company Profile
Xi 'an ESM Tech Co. Ltd launch its journey as a quality products manufacturer. We are currently producing precision series of products like pressure transmitter ,differential pressure transmitter,ultrasonic sensors, ultrasonic level meter, displacement sensors, safety light curtain sensor,float switch, flow meters etc.
A core of highly profession and experience engineers are engaged with us for research and development process. Our range of equipment boundary expanded recently to GPS tracking equipment .
Since its establishment, the company growing up to a design and supply chain services. We, developed into a sensor and GPS tracking solution provider, for distributors and agents both at home and abroad.
Today, the company based on the "people-oriented, scientific and technological innovation" concept of the camp, with customers "buy for peace of mind with assured quality", to set foot in the world market.
Welcome to Xi 'an ESM Tech with innovative solution worldwide.
