YKMC-160 37KW Pulse Bag Dust Collector Dust Collection System
US $6,000.00-12,000.00 / set
1 set(s)Minimum order
condition:
New
minimum particle size:
1 micron
place of origin:
Jiangsu, China
brand name:
YORKTECH
dimension(l*w*h):
5mX2.1mX4.5m
weight:
900 kg
Privacy Policy:
Samples are free within a certain price range
Other recommendations for your business
$1,800.00-2,000.00
1 set (MOQ)
$1,800.00-2,000.00
1 set (MOQ)
$6,000.00-12,000.00
1 set (MOQ)
$6,000.00-12,000.00
1 set (MOQ)
$1,800.00-2,000.00
1 set (MOQ)
$1,400.00-1,500.00
1 set (MOQ)
$1,400.00-1,500.00
1 set (MOQ) Contact us
Quik Detail
| condition | New |
|---|---|
| minimum particle size | 1 micron |
| place of origin | Jiangsu, China |
| brand name | YORKTECH |
| dimension(l*w*h) | 5mX2.1mX4.5m |
| weight | 900 kg |
| warranty | 1 Year |
| Power | 37kW |
| Air volume | 36000m3/h |
| Filter bag Qty | 160 |
| Bag size | 133mm X 2000mm |
| Dimensions | 5mX2.1mX4.5m |
| Application | Stone crusher, Sandmaking, Cement Plant, Asphalt Plant, |
| Product Material | Q235 steel |
| Warranty | 1 year |
| Applicable Industries | Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Farms, Printing Shops, Construction works , Food & Beverage Shops |
| Showroom Location | None |
| Video outgoing-inspection | Provided |
| Machinery Test Report | Provided |
| Marketing Type | New Product 2020 |
| Warranty of core components | 1 Year |
| Core Components | PLC, Engine, Bearing, Gearbox, motor, Gear, Pump |
Product Detail
Product Overview
YKMC-160 37KW Pulse bag dust collector dust collection system
YKMC bag house dust collector is a new type of dust collector with high efficiency at international levels. It combines the advantages of sub-room reverse flow and jet pulse bag house together, which over-comes the weakness of low strength of dedusting, the defects of cleaning dust and filtering which causes dust absorption twice for expanding the application range of bag filter.
The collector adopts efficient offline cleaning, which leads to high effectiveness, long service life of filter bag, low resistance, and so on. It is widely used in building materials, metallurgy, chemical industry for purifying dust.
This collector is outdoor type formed by different chambers and filter bag in several kinds of types, which are 32, 64, 96 and 128. The diameter of filter bag is Φ130mm and length 2450mm or 3060mm. Discharging concentration could be less than 20mg/Nm³ if concentration of collecting dust is less than 1000g/Nm³. When outside temperature is less than or equal to 5-25 , the heating device should be installed.
The collector adopts efficient offline cleaning, which leads to high effectiveness, long service life of filter bag, low resistance, and so on. It is widely used in building materials, metallurgy, chemical industry for purifying dust.
This collector is outdoor type formed by different chambers and filter bag in several kinds of types, which are 32, 64, 96 and 128. The diameter of filter bag is Φ130mm and length 2450mm or 3060mm. Discharging concentration could be less than 20mg/Nm³ if concentration of collecting dust is less than 1000g/Nm³. When outside temperature is less than or equal to 5-25 , the heating device should be installed.
Product Paramenters
YORK Filter bag dust collector | YORK Filter bag dust collector | |||||||||
Model | Power | Air volume | Filter bag Qty. | Bag size | dimensions | |||||
YKMC-64 | 11KW | 12000m3/h | 64 | φ133mmX2000mm | 2mX1.5mX4m | |||||
YKMC-80 | 15KW | 15000m3/h | 80 | φ133mmX2000mm | 3mX2.1mX4m | |||||
YKMC-96 | 18.5KW | 20000m3/h | 96 | φ133mmX2000mm | 3.6mX2.1mX4m | |||||
YKMC-120 | 22KW | 26000m3/h | 120 | φ133mmX2000mm | 4mX2.1mX6m | |||||
YKMC-160 | 37KW | 36000m3/h | 160 | φ133mmX2000mm | 5mX2.1mX4.5m | |||||
YKMC-200 | 37KW | 37000m3/h | 200 | φ133mmX2000mm | 5mX2.1mX4.5m | |||||
YKMC-400 | 45KW | 42000m3/h | 400 | φ133mmX2000mm | 7mX2.1mX4.5m | |||||
YKMC-600 | 110KW | 120000m3/h | 600 | φ133mmX3000mm | 12mX3mX7.5m | |||||
Details Images
Main features
1.Cleaning dust offline and effectiveness is about to 99.9%. The dust collector has no secondary absorption, specially good when used for handling high concentrated gas.
2.Use reverse blowing in high temperature to prevent condensation effectively.
3.Use new materials for cleaning dust. It can adapt to various conditions.
4.Because of automatic control, the machine is easy to be operated with good reliability.
5.The dust collector is with air box, which avoids partial damage inconvenient installation.
2.Use reverse blowing in high temperature to prevent condensation effectively.
3.Use new materials for cleaning dust. It can adapt to various conditions.
4.Because of automatic control, the machine is easy to be operated with good reliability.
5.The dust collector is with air box, which avoids partial damage inconvenient installation.
Industrial dust filter bag
Different premium material for choice
Laser cutting of high quality steel
Selected premium quality carbon steel 201/301 stainless steel
Pure copper high quality centrifugal fan
Pulse valve dust cleaning device
Indoor dust duct laid out
Customized design according to customer site conditions
Customers' Feedback
Similar Products
Company Profile
Established in 2008, located in Wuxi New- district Industrial Park, in Wuxi City,Jiangsu province. Wuxi YORK is a comprehensive
enterprises which integrates researching, manufacturing,market developing and service. YORK Environmental Protection Machinery,
specialize in design, R&D and manufacture all kinds of dust collectors, dust collection systems and fume extractors etc.
At present, our company products have been all over the country's major provinces and cities, we have exported to more than 60
countries and regions.Our products have been widely recognized and highly praised by customers.
Strength: YORK accepts OEM and ODM, satisfy customer’s personalized requirements.
One-stop: YORK provides a wide range of products to satisfy customers with one-stop purchase.
Service: YORK offers lifelong after-sales service for every product.
Quality: Every product gets passed strict quality inspection, the final passed yield is over 99.9%.
enterprises which integrates researching, manufacturing,market developing and service. YORK Environmental Protection Machinery,
specialize in design, R&D and manufacture all kinds of dust collectors, dust collection systems and fume extractors etc.
At present, our company products have been all over the country's major provinces and cities, we have exported to more than 60
countries and regions.Our products have been widely recognized and highly praised by customers.
Strength: YORK accepts OEM and ODM, satisfy customer’s personalized requirements.
One-stop: YORK provides a wide range of products to satisfy customers with one-stop purchase.
Service: YORK offers lifelong after-sales service for every product.
Quality: Every product gets passed strict quality inspection, the final passed yield is over 99.9%.
Certifications
FAQ
Q1：Which shipping methods do you use?
A1:We offer sea, air, and land freight as well as express delivery. The specific options depend on the quantity of the order.
A2：We accept T/T,L/C,D/P D/A,MoneyGram,Credit Card,PayPal,Western Union,Cash,Escrow.
Q3：What about the Minimum Order Quantity?
A3：The MOQ is 1 pcs.
