China Made Corn Pneumatic Planter Tractor 6 Rows Maize Vacuum Seeder With Fertiliser Hopper Sunflower Vegetable Precision Seeder
1 set(s)Minimum order
number of rows:
4, 5, 6
type:
planter
application:
soybeans,sorghum, mung beans,corn
use:
Air Suction Precision Seeder
place of origin:
Shandong, China
weight:
1700 KG
Privacy Policy:
Samples are free within a certain price range
Other recommendations for your business
$2,372.00-2,886.00
1 set (MOQ)
$780.00-1,120.00
1 parcel (MOQ)
Contact us
Quik Detail
| number of rows | 4, 5, 6 |
|---|---|
| type | planter |
| application | soybeans,sorghum, mung beans,corn |
| use | Air Suction Precision Seeder |
| place of origin | Shandong, China |
| weight | 1700 KG |
| dimension(l*w*h) | 2450*3150*1450mm |
| warranty | 1 Year |
| key selling points | Multifunctional |
| machinery test report | Not Available |
| video outgoing-inspection | Provided |
| core components | Gear, Gearbox, Bearing |
| Applicable Industries | Farms, Home Use, Retail |
| Showroom Location | None |
| Condition | New |
| Marketing Type | Ordinary Product |
| Warranty of core components | 1 Year |
Product Detail
When no tillage fertilization sowing or iron stubble sowing, the power of the tractor is directly transmitted to the middle air suction fan through the universal joint transmission shaft for action and rotation. When the plow body comes into contact with the ground, the straw and stubble on both sides of the sowing ditch opener are cut off and buried in the soil; The following fertilization and sowing trenchers push the straw and stubble to both sides of the fertilization and sowing positions while opening the trench; The rear depth limiting pressure wheel rotates by friction between its own weight and the ground, and is driven by a transmission shaft to drive the fertilizer and seed discharge mechanism to implement fertilizer and seed discharge. The discharged fertilizer enters the sowing and fertilization trencher through the seed and fertilizer transport pipes, and then falls into the groove opened by the trencher. The rotating pressure wheel compacts the soil in the groove, completing the operation of no tillage fertilization and sowing or iron stubble sowing.
project | Design value | Design value |
model name | 5-row air suction seeder | 6-row air suction seeder |
structural style | Pneumatic; Suspended type | Pneumatic; Suspended type |
Supporting power range | ≥110KW | ≥73KW |
Number of work lines | 5 rows | 6 rows |
Fan Type | Centrifugal | Centrifugal |
Fan impeller diameter | 400mm | 400mm |
outline dimension | 2450*3150*1450mm | 2450*3150*1450mm |
weight | 1420kg | 1700kg |
Fully enclosed gearbox, adjustable to 16 gears for sowing crop spacing,
The distance for fertilization can be adjusted to 8 gears.
Overall depth limit、The depth limit of the sowing unit is independently adjustable.Excellent performance.
Full gear transmission of the seeder,Not easily damaged.
The overall frame is thickened ,Never deform.
Imported fan,Safe and reliable.
Stainless steel thickened fertilizer box,It can hold 1 ton of fertilizer.
Increase and thicken the seeding box,Profiling floating sowing legs.
Production and after sales services
1. We can customize the products color according to customers real needs;
3. After sales, we will provide special technicians for solving customers questions.
2. We can customize the nameplate for customers according to their request;
COOPERATING WITH US, BE ASSURED!!!
